产品简介

Product Introduction

运行成本低：与常规机械搅拌式浮选机比较能节电1/3~1/2。分选精度高，精煤灰分低：精煤灰分可比常规机械搅拌式浮选机降低1~2%。浮选效果好：内装有液面自控贺电控装置，泡沫细化程度高，从而提高了浮选的效果。易损件耐用性强：叶轮在机内一直处于活动状态，起到在清除积料和杂物的作用，减少了因杂物而损坏部件的现象：且搅拌装置的叶轮由磨橡胶制成，增强了耐磨度。

Technical parameters

技术参数

型号	槽容积(m³)	内部尺寸（长×宽×高）(m)	空气吸入量(m³.min)	安装功率(kw)	电动机型号	生产能力（m³/min）
BF-0.37	0.37	0.74×0.74×0.75	0.9~1.05	1.5	Y90L-4	0.2~0.4
BF-0.65	0.65	0.85×0.95×0.9	0.9~1.10	3.0	Y132S-6	0.3~0.7
BF-1.2	1.2	1.05×1.15×1.10	1.0~1.10	5.5 4.0	Y132M2-6 Y132M1-6	0.6~1.2
BF-2.0	2.0	1.40×1.45×1.12	1.0~1.10	7.5	Y160M-6	1.0~2.0
BF-2.8	2.8	1.65×1.65×1.15	0.9~1.10	11	Y180L-8	1.4~3.0
BF-4.0	4.0	1.9×2.0×1.2	0.9~1.10	15	Y200L-8	2~4
BF-6.0	6.0	2.2×2.35×1.3	0.9~1.10	18.5	Y225S-8	3~6
BF-8.0	8.0	2.25×2.85×1.4	0.9~1.10	22 30	Y225M-8 Y250M-8	4~8
BF-10	10	2.25×2.85×1.7	0.9~1.10	22 30	Y225M-8 Y250M-8	5~10
BF-16	16	2.85×3.8×1.7	0.9~1.10	37 45	Y280S-8 Y280M-8	8~16
BF-20	20	2.85×3.8×2.0	0.9~1.10	37 45	Y280S-8 Y280M-8	10~20
BF-24	24	3.15×4.15×2.0	0.9~1.10	45	Y280M-8	12~24
